| Model | JVS-A816-HYC | |
| Camera | ||
| Image Sensor | 1/2.9″ CMOS Sensor | |
| Image Resolution | 1920×1080 | |
| Effective Pixels | 2.0MP | |
| TV System | PAL/NTSC | |
| Signal mode | AHD/ TVI/ CVI/ CVBS | |
| Electronic Shutter | Auto | |
| S/N Ratio | ≥39dB | |
| Scanning System | Progressive Scan | |
| Lens | ||
| Lens | Board Lens 3.6mm/F2.0 | |
| Lens Type | Fixed | |
| Auto Iris Support | N/A | |
| Night Vision | ||
| Warm LED | 28µ x 4Pcs | |
| LED Light Distance | 15m. | |
| IR Cut Filter | N/A | |
| LED Status | Turn on below 7Lux | |
| LED Control | Software Control | |
| Day & Night | Full Color | |
| Camera Features | ||
| OSD Menu Language | Optional | |
| White Balance | Auto | |
| Gain Control | Auto | |
| Noise Reduction | 3D DNR | |
| Picture Adjustment | N/A | |
| WDR | DWDR | |
| OSD Support | Optional | |
| Audio | Built-in mic | |
| UTC | Optional | |
| General | ||
| Housing | Plastic + Metal | |
| Bracket | Yes | |
| Operation Temperature | -10°C ~ 50°C | |
| Working Humidity | 10% ~ 90% | |
| Power Source | DC12V±10%, 230mA | |
| Dimension | 184x69x65mm | |
| Weight | ≤200g | |
